What are you building right now?

No build log yet. I need to get things organized around the house first.

A post was split to a new topic: Building out your lab

So @ChrisGammell, did you cobble something together?

Ended up only having time to cobble together the talk I had to give, not a hack

1 Like

It looked like there were some pretty cool hacks, maybe next year.

Did they record your talk?

Sadly, we did not record the talk. I plan to give this particular talk again in the future though.

1 Like

I can relate :slight_smile: My hack also suffered from having to do an unplanned Maker Faire talk.

Iā€™ve finally got some documentation in place for it and will write a blog post soon. Hereā€™s the shared project:

E-Paper Badge with Teensy LC designed in KiCad
Photo of E-Paper Display

Iā€™m glad Hardware Happy Hour (3H) Chicago is next week, so Iā€™ll be able to show my improvements since Bring-A-Hack.

-Drew

4 Likes

I just finished building an 8-bit computer based on the Hitachi HD6309 microprocessor for the Retro Challenge 2017/04:

The design, layout and debugging was done in a month, mostly during the weekends. A full blog is here: https://namoseley.wordpress.com/category/retrochallenge/

Iā€™m currently writing my own Pascal compiler + virtual machine so I can move away from assembler-only program development.

Other things on my bench include an RF mixer based on a diode ring and a discrete audio amplifier.

Regards,
Niels.

3 Likes

Wow, thatā€™s an impressive project!

Thanks! I highly recommend taking part in the Retro Challenge. Itā€™s a great excuse to work on something completely ā€œuselessā€. The next one is scheduled in October 2017.

Currently Iā€™m working on YANC (Yet Another Nixie Clock). Itā€™s a IN-16 based nixie clock, time sync via WLAN/NTP, alarms, timed night mode (switching off HV / tubes to preserver lifetime), alarm melodies from arbitrary .wav files. Display dimming with environmental brightness. Tube backlighting. Settings via webpage (each unit has its own), or per IR controller that comes with the unit.

Hereā€™s what it will look like.

Dimensions: 12cm x 7cm x 2cm (case heigth) / 6cm (incl. tube height). So it is really small. Every body seeing it till now exclaimed ā€œOH, sooo cute. Can I have one?ā€. Would be a nice marketing punch line. Only that I do not intend to sell it large scale. Or at any scale. However, the product was designed ready for professional manufacturing and assembly, test points, test rig and all, just for the fun of it. Iā€™m still looking for an affordable manufacturer for the Aluminium body, with is machined from a solid block.

I will post pictures of the boards. As I am a new user here (although a regular in Kicad forum) I am restricted to 1 pic per post, so there will be 2 follow up posts.

The project was started with EAGLE and then migrated to KiCad.

1 Like

And here is the promised glimpse on the inner workings, part 1: two tightly stacked boards, one for the MCU and stuff and the other for tube mounting and the HV drivers.

[EDIT] Oh yes: the missing 3D models for some parts are due to my lazyness. Simply wouldnā€™t go to the trouble and create them :slight_smile:

3 Likes

And here is the promised glimpse on the inner workings, part 2: two tighly stacked boards, one for the MCU and stuff and the other for tube mounting and the HV drivers.

3 Likes

Wow, that looks great! Did you end up needing to model a lot of the 3D yourself?

1 Like

No. Thatā€™s why some models are missing: too lazy :slight_smile:. Those that are here are either KiCad (thanks to Shack, Maui. and some other giants) or from GrabCad, 3dConentCentral, available manufacturer models atl.

As I earned ā€œBasicā€ right now, I can afford another post. Backside of the MCU board. At left is the SD card holder (you have to imagine that in your mindā€™s eye. Lazy, remember?).

Reference grade audio ADC and DAC. Iā€™m spending more time trying to decide what should be on the front panel (metering? LEDs or LCD or OLED display? buttons?) than the rest of the design. And that includes working up the clocking.

With audio it seems like there is never enough on the panel, just do it all :stuck_out_tongue:

1 Like

Great stuff! The nixie project deserves its own build log :slight_smile:

1 Like

Thanks :slight_smile:, I came to think the same. Will open up a log thread and migrate the previous posts there.
ā€¦ Really Soon Now :wink:
