Best Dif analog logic analyzer?

Equipment
1

Hi!

I’m using Salea logic 8 pro it’s great but need something similar size as it’s dropped inside a robot but as I have multiple CAN busses at 1Mhz I need multiple DIF measurements. And orsiloscope standard size is way too big. About salea or about 3 times bigger max.

Any suggestions?

2

Use sigrok’s pulse view with any of the supported hardware

Ken Tindell’s setup below.

1 Like
3

But that is the question. What good dif measurement hardware exist for multiple channels 50Mhz+ which also can do logic analysis. The can is completely free floating I tried using the system ground but it did not work…

4

Take a look at this one

Diff inputs, high rate, CAN

Another

1 Like
5

Thank you! But those don’t look like analog and digital. I need to see signal integrity as it’s a noisy system and many devices on the buss.
